I-High Energy Energy Storen Battery 10KWh

Ukubuka konke komkhiqizo:

Kwethulwa ibhethri lethu lokusika eliphakeme "eliphansi le-voltage yebhethri - 51.2v 10kWh," isixazululo sezinguquko sokugcina amandla okuhlala. Lolu hlelo lwezwe-we-art-of-art lunikeza amandla athembekile atholakalayo, qinisekisa ukunikezwa kwamandla ekhaya lakho. Ngokugxila ekuphepheni, ukuklama ukuguquguquka, kanye nokukhubazeka, lolu hlelo lokugcina amandla ekhaya luphelele kugridi kanye nempilo yegridi.

Izicelo:

Uhlelo lwethu lwe-10kW Solar kanye nohlelo lwe-Off-Grid Solar lwenzelwe izinhlobo eziningi zezicelo, kufaka phakathi:

• Isitoreji Samandla Sokuhlala: Gcina ikhaya lakho linikwe amandla ngesikhathi sokuphuma futhi sehlise ukuthembela kwakho kugridi.
• Isitoreji samandla Ekhaya: Gcina amandla ngokweqile kusuka kumaphaneli akho elanga ukuze usetshenziswe lapho uludinga kakhulu.

Izici:

• Ukuphepha Okokuqala: Isistimu yethu isebenzisa amaseli we-Prismatic Life Pow ende, eqinisekiswe ukuphepha (i-UN38.3, Rohs, IEC62619, UL1973, UL954A). Ngomklamo ophansi we-voltage, kuphephile ngokwemvelo ukuze kusetshenziswe indawo yokuhlala.
• Idizayini eqinile: Idizayini ye-IP65 yamanzi ivumela ukufakwa kwangaphandle, futhi iyavumelana nezimo, ifakwe kalula ngodonga, futhi isebenza kulo lonke uhla lokushisa olubanzi (-20 ~ + 55 ° C). Futhi, kucishe kube yisondlo.
• Impilo Ephakeme Ephakeme: Jabulela impilo yomjikelezo yemijikelezo engaphezu kuka-6000, uqinisekise ukuthembeka kwesikhathi eside.
• Ukukhubazeka: Uhlelo lusekela ukuxhumeka okuhambisanayo kwekhono lokugcina amandla amaningi futhi kunikezela ngokulahleka okukhulu kwamanje kwe-200a. Iyahambelana nabakwa-inverters abakhulu, kufaka phakathi i-SMA, iVictron, Megarevo, i-GrawnAtt, nokuningi.
• Uhlelo Lokuphathwa Kwebhethri : Zuza ohlelweni oluzimele lokuvikela olwenzelwe ukukhokhisa nokukhipha, nge-real-time state-of-Chesha (SOC), isikhathi sokusebenza (runtime), kanye ne-alamu (i-alamu) ekhombisa. Futhi, kukhona isoftware ye-PC yokusebenza okuningiliziwe. Izici eziningi zokuvikelwa, ezinjenge-voltage engaphezulu (i-OVP), i-low-voltage (LVP), ngaphezulu - (i-OCP), amazinga okushisa aphansi (i-LTP), asendaweni yokuvikela imali oyitshalile.
• Isikhombimsebenzisi sokuxhumana: ama-Rs485 futhi amachweba okuxhumana angatholakala ngokuhlanganiswa okungenamthungo nama-inverters.

Ukucaciswa:

• Imodeli: I-Bat-10KWH-51.2v-200a
• I-voltage ye-NOSRONG [V]: 51.2
• Umthamo oqanjiwe [ah]: 200
• Amandla aphelele [wh]: 10,240
• Ubukhulu (WDH, MM): 520 * 165 * 865
• Isisindo [kg]: 96
• UMax. Ukushaja okwamanje [a]: 200
• UMax. Ukukhipha Amanje [A]: 200
• Ukukhishwa kwe-Pulse kwamanje: 210a @ 10min, 220a @ 10s
• I-Charging Voltage [V]: 55.2 ~ 57.8
• Ukuphela kwe-voltage [V]: 44.8 (Isipele Isicelo) / 50 (Isicelo Somjikelezo)
• Umswakama Wokusebenza: 0 ~ 95% RH (akukho maling)
• Uhla lokushisa olusebenzayo: Umkhiqizo ojwayelekile: Ukushaja: 0 ~ + 55 ° C; Ukudonswa: -20 ~ + 55 ° C nge-heater ongayikhetha: ukushaja / ukukhipha: 30 ~ + 55 ° C
• Ukuphila Komjikelezo:> 6000 (25 ° C, 0.5c / 0.5c, 90% Ukujula kokukhishwa kanye nama-70% ukuphela kwempilo)
• Impilo yeKhalenda Eklanyelwe: Iminyaka eyi-10
• Isikhombimsebenzisi sokuxhumana: I-RS485, ingakwazi
• Ukuvikelwa: Amandla aphezulu, ama-voltage aphansi, ukweqiwa okuphezulu, ngaphezulu kokushisa, izinga lokushisa eliphansi, umjikelezo omfushane
• Ukuxhaswa okuhambisanayo (2): Yebo, max. Amasethi ayi-15
• Ukuxhaswa kochungechunge: Akusekelwa

Zizwa ukuhlinzekwa kwamandla okuthembekile kanye nokuzimela kwamandla ngebhethri lethu eliphansi eliphansi - 51.2v 10kWh. Lolu hlelo lwenzelwe ukufeza izidingo zakho zokugcina amandla okugcina amandla, ukuhlinzeka ngokuphepha, ukuguquguquka, kanye nekhono lokukala amandla akho okugcina amandla njengoba kudingeka. Ithi kahle kuma-blackouts futhi sawubona emandleni angaphazanyiswa ekhaya lakho.
